The mechanical transmission system all adopts precision rolling bearings and the precision gears and racks with machining accuracy of the national standard 7 grade.
The drive system adopts a domestic high-subdivided motor. At the same time, in the horizontal and longitudinal gear transmission structure, an automatic gap compensation device is added, so that the transmission structure can accurately execute the instructions issued by the CNC system.
PRODUCTS VIDEO
The beam adopts imported technology, a desktop frame, and a structure that better eliminates the torsion moment. The beam is a steel profile structure, so that it will not be deformed during long-term use.Technical Parameters
| MODEL | 1313 / 1325 | 1530 / 2040 | 2060 |
| CUTTING AREA | 1300*1300MM / 1300*2500MM | 1500*3000MM / 2000*4000MM | 2000*6000MM |
| WORKING AREA | LGK63-200A |
| CUTTING THICKNESS | 6-35mm |
| MAXIMUN OPERATING SPEED | 15000mm/min | ||
| OPERATING MODE | Non-contact arc ignition | ||
Cutting samples
It is suitable for low-carbon steel, copper, iron, aluminum, galvanized, titanium and other metal plates.
Download Zone
More downloadsApplication industry
Kitchen appliances,sheet metal case cabinets,machinery equipment,electrical equipment,lighting hardware,advertising signs,auto parts,display equipment,various metal products,sheet metal cutting and processing industries.
